Harlequin Hydroclear 6 Person Sewage Treatment Plant - HC6

The Harlequin Hydroclear 6 Person Sewage Treatment Plant is the market leader with pollutant removal level of 97%. Wastewater from toilets, showers, kitchens etc is fed directly into the treatment plant, and out the other end comes clarified effluent suitable to be discharged into a soakaway or stream. Market-leading performance, easy installation, virtually inaudible operation, low maintenance costs, reliable bio media system and durability are all qualities that make the product best suited for all off-mains sewage treatment requirements.

As standard the Hydroclear HC6 comes as a Gravity Discharge System, if required this can be upgraded to a Pumped Discharge System.

Specification:

• Compliant with EN-12566 part 3
• Population Served: 1 to 6
• Max. Hydraulic Load: 1200 litres /day
• Organic Load: 480g BODs/day
• NH3: 48g/day
• Total Capacity: 4770 Litres
• Length: 2400mm
• Width: 1620mm
• Height to Ground Level: 2000mm
• Empty Plant Weight: 330kg
• Energy Usage: 1.8kWh/day
• Service Interval: Up to 24 months depending on the number of inhabitants
• Inlet Depth: 500mm (can be increased with the use of risers)
• Outlet Depth: 630mm
• Requires 230V, 75W Power Supply

Options:

• Invert Depth (can be increased by adding risers)
• Outlet: Gravity as Standard, Pumped available
• Air Blower Function Alarm (mains powered): To alert you if the air blower fails. The air blower helps to keep the plant running efficiently

Extra Information Downloads
HC6 Specification Sheet
HC6 Drawing
Harlequin Waste Water Sales Brochure

Key Benefits of the Harlequin Hydroclear HC6

Virtually Inaudible – High performance diaphragm blowers are used and externally housed achieving a virtually silent operation.
Odourless – The system is hermetically sealed, coupled with a market leading treatment performance eliminates odour.
MBBR Technology – Moving Bed Biological Reactor (MBBR) systems are self-cleaning and unable to become blocked through channelling unlike most fixed film media systems.
Market leading performance – Producing an excellent 96.6% pollutant removal level, the final effluent can be directly discharged into a stream or soakaway.
Low Maintenance Costs – Chamber one capacity is as much as 66% larger than other plants, making desludging intervals up to three times longer saving the owner significant costs.
Power Failure Default – The system keeps performing as a septic tank in the event of a power failure.
