Harlequin 1400 Litre Diesel Dispenser - 1400FP

This Plastic Bunded Diesel or HVO Dispensing Tank from Harlequin gives the user a diesel delivery system similar to forecourts. Each Diesel and HVO Tank comes complete with an Electric Pump (230V), 6 metres of Delivery Hose,10 micron water and particulate filter and an Auto Shut Off Nozzle. All of the pumping equipment is contained within the lockable cabinet for security. With a 1400 litre capacity this Harlequin 1400FP Fuel Point has a 10 year guarantee on the bunded diesel tank and 1 year guarantee on pump.

Delivered complete with:

• 230 Volt Pump - Connect straight to mains by plug or can be hardwired
• 56 Litres a Minute Flow Rate - (Most forecourts deliver fuel at around 30 Litres a minute)
• 10 Micron Filter - A Filter fitted inside the cabinet to remove dirt from fuel
• 6 Metres of Delivery Hose
• Automatic Shut Off Nozzle - When the vehicle being filled is full the nozzle cuts off supply so you can´t overfill.
• Lockable Cabinet to store all equipment - Complies with UK Storage Regulations

Optional Extras:

• Mechanical Flow Meter - Fitted inside the cabinet, a 3 digit resettable meter to show how much has been dispensed each time, also has a 6 digit NON resettable meter to show the all time amount dispensed in litres.

Tank Dimensions:
Length: 1610mm
Width: 1570mm
Height: 1880mm
Weight: 150kg
Brim-full Capacity: 1498 litres

HVO (Hydrotreated Vegetable Oil) biodiesel is produced from 100% renewable resources and is an excellent, environmentally friendly biofuel.

Existing diesel engines do not require modification to use it. You can even top up a tank already containing mineral diesel with HVO as the two liquids mix together without any problems.

Harlequin Manufacturing have been making these bunded diesel tanks for over 20 years so they have a proven track record. Harlequin are market leaders but still offering excellent value.
Each tank is visually inspected for quality and tested with compressed air to ensure tank is air tight before it leaves the factory.
