10000 Litre Underground Water Tank - Graf Carat XL

The Graf Carat 10,000 Litre Underground Storage Tank is suitable for Non-Potable Water, Wastewater, Raw Sewage, Effluent, Silage, Slurry, Rainwater, Grey Water & Blue Water.

CARAT tanks are manufactured from high-quality, robust, polypropylene and supplied fully assembled except for the domes which are supplied separately for fitting on-site by others. The Carat range can be installed using granular or concrete backfill options, subject to ground conditions & groundwater level.

Specification:

• 10000 Litres high-quality, robust, polypropylene tank & related accessories for use with a wide range of media
• Telescopic dome shaft, with PE-lid (for pedestrian loading)
• 15 Year Warranty on Tank
• Simple & quick to install
• Adjustable lid height for flush alignment to ground level
• All tank dome, riser & lid connections include high-quality thick rubber gasket for watertight seals
• Granular or concrete backfill options, subject to ground conditions & groundwater level.
• Additional inlet/outlet, with sealing set DN 100, can be core drilled into the shoulder of the tank
• Multiple tanks can be connected to increase storage capacity if required, with low-level connections with sealing set DN 100

Tank Dimensions:

• Length: 3520mm
• Width: 2240mm
• Height Without Turret: 2285mm
• Weight: 460kg
• Technical Drawing

Common Applications:

• Non-potable water
• Wastewater
• Raw sewage
• Effluent
• Silage
• Slurry
• Rainwater
• Grey water & blue water
